T-LINE
SINGLE ROUND
HOUSINGS
SPECIAL
PI
C
B
A
**Option
3
2
1
Special T-Line single round housings are
designed for sanitary and non-sanitary
range of air and gas filtration applications.
The housings are made of high quality
SS316L stainless steel (for pharma /
biotech applications) and other suitable
MOC as required, to be compatible with the
contact fluid. Housings come with gaskets
and O-rings compounded only from FDA
approved materials. The housing can also
be provided with a choice of sanitary and
non-sanitary vent and drain valve options.
The Inlet and outlet end connections
are either flanged or standard triclamp
connections. The housing can fit one
single cartridges of multiple lengths to
suit required flow rates.
Air Vent
SS316L
Mirror finish
Triclamp or
flanged ends
4
Sealed diaphragm
pressure gauge*
** Higher temperature or Pressure
compatibility design available on request.
* Other MOC available as required
See Page No. 22 for Ordering information
BENEFITS
• Easy cleaning and optimum flush
liquid requirement
• Quick opening and closing of the
dome hence less labour
• Precision engineering with low
tolerance ensures precise cartridge
locking in place.
• High surface finish ensures ease of
cleanability
Specifications
Head and bowl : SS 316 L / SS 304*
Legs and clamps : SS 304
‘O’ ring seal
: Silicon / PTFE / Viton / EPDM
Mirror : Internal /External
Max Op Pressure (Pmx): 15 bar (218 Psig)**
140 °C (284 °F)
Design (Pmx)
: 1.5 times
Tested (Pmx)
: 1. 2 times
Material of construction
Surface finish
Max operating temperature
Operating pressure
Special Coatings
PP / PTFE / PVDF for corrosive liquids
T-LINE
SPECIAL
T-LINE
SPECIAL
Note: Specifications and dimensions may change. Please check with us before ordering.
FEATURES
• All wetted parts with customized
MOC with customized finish.
• Housings can accommodate a
single round of filter cartridges of
5/10/20/30/40 inches long.
• CIP and SIP capability for pharma/
Biotech requirements with in situ
integrity testing capability
• Optionally with sanitary and non-
sanitary valves for vent, inlet and
outlet.
• All housings with complete
documentation for
validation
• All gaskets and polymers
compounded as per US FDA
approved polymers
SPECIFICATIONS
FEATURES
*Pressure Gauge shown is not a part of standard offering
T LINE HOUSING
(PART NO)
DESCRIPTION A B C
A0407-01057BC 05” LONG 265 510 235
A0407-01107BC 10” LONG 386 631 235
A0407-01207BC 20” LONG 641 886 235
A0407-01307BC 30” LONG 908 1153 235
A0407-01407BC 40” LONG 1161 1406 235
Note: All end connection are flanged or triclamp type.
